ZXP pneumatic film through a single seat control valve

ZXP new series pneumatic film through single seat control valve adopts top guide structure, with multi-spring actuator. It has the advantages of compact structure, light weight, sensitive action, S-streamlined fluid channel, small pressure loss, large valve capacity, accurate flow characteristics and convenient disassembly.

ZMAN(P)(M) pneumatic film control valve

ZMAN(P)(M) pneumatic thin film control valve is commonly used as a pneumatic actuator, it USES a balance valve core structure, axial unbalance force is small, good stability, stem should not produce vibration, allow large pressure difference, low noise, large flow capacity, strong adaptability and make in the flow, pressure difference, leakage requirements are not high occasions

ZJHP, ZJHM fine pneumatic thin film through a single seat, sleeve control valve

This series of products are standard type, adjustable cut off type, bellows seal type, jacket insulation type and other varieties. The nominal pressure class of the product is PN16, 40 and 64; Nominal diameter range DN20 ~ 300. The applicable liquid temperature ranges from -200℃ to +560℃. Leakage standard levels have Ⅳ or Ⅵ, flow characteristic of linear or equal percentage.

ZMABP, ZMABN pneumatic film through two - seat control valve

This series of products are standard type, bellows sealing type, jacket insulation type and other varieties. The nominal pressure class of the product is PN16, 40 and 64; Body diameter range DN25 ~ 400. The applicable fluid temperature ranges from -250℃ to +560℃. Standards for the leakage Ⅲ level and Ⅳ level. The flow characteristics are linear or percentage. A variety of varieties

ZJHQ, ZJHX pneumatic film tee junction, split control valve

This series of products have three - way confluence and three - way shunt. The nominal pressure is PN16, 40, 64; Nominal diameter range DN25 -- 300. The applicable fluid temperature ranges from -60℃ to +450℃. The standard for the leakage Ⅳ level. There are two kinds of flow characteristics: straight line and parabola.

ZXS new series pneumatic film Angle single seat control valve

ZXS new series pneumatic thin film Angle single seat control valve adopts top guided structure, equipped with multi-spring actuator, with compact structure, light weight, sensitive action, large valve capacity, S-streamline fluid channel, small pressure loss, large valve capacity, accurate flow characteristics, convenient disassembly and other advantages.

ZXX (Q) pneumatic film tee high temperature control valve

ZXX (Q) pneumatic film three-way high temperature control valve adopts a cylindrical thin-wall window spool structure, which is different from the plunger spool bushing guide. Equipped with multi-spring actuator, it has advantages of compact structure, light weight, small volume and convenient disassembly and assembly.

ZXN pneumatic film through two - seat regulator

ZXN new series pneumatic film two-seat control valve adopts double guide structure, with multi-spring actuator, with compact structure, light weight, sensitive action, large valve capacity, accurate flow characteristics, convenient disassembly and other advantages.

ZXM pneumatic film through sleeve control valve

ZXM - series pneumatic film sleeve valve is a pressure balance control valve. Equipped with multi-spring actuator, the overall mechanism is compact, light weight and stable. The fluid channel is S streamlined, with small pressure loss, large allowable pressure difference, small noise and large flow capacity.
