Nominal pressure: 0.6MPax I.OMPa、1.6MPa、2.5MPa、150Lb Nominal diameter: DN50~2000 mm NPS 2 »~80« Suitable temperature: -38—+1100^ (Range of temperature subject to the material of sealing and property of medium ) Connecting flange： ANSI B16.5. GB/T9113, HG. SH、JIS、DIN、NF、BS Main materials : Cl. WCB. ZG1 Cr18Ni9Ti. ZG1 Cr18Ni 12Mo2Ti.CF8.CF8M. CF3. CF3M 2Cr25NI20、UB6(904L) Seal type: Stainless steel hard seak Teflon soft seal Leakage: Stainless steel hard seal: Grade D(Liquid 0.1 XDN mm3/s) Teflon soft seal: Grade A (Zero Leakage) Accessories: Flange

506X water hammer relief valve has incomparable advantages such as compact structure, long life, automatic pressure relief and waterproof hammer. This valve can be widely used in the bypass of the water pipeline at the outlet of the pump in order to protect the equipment after the pump from being damaged by the water hammer after stopping the pump. when the water hammer comes, through the control of external piping, the valve opens and relieves pressure.
